Specs
hp rating: 1250 HP
generation: T4 DIVIDED 4-BOLT
cover style: H-COVER
compressor inducer: 76.0 MM
Details
HP Compressor Cover: 4” inlet / 3” outlet
Compressor wheel Inducer: 76.45mm
Compressor wheel Exducer: 102.36mm
Turbine wheel Inducer: 81.99mm
Turbine wheel Exducer: 75.13mm
Max Shaft Speed: 134,340 RPM
Flow Rate: 125 lbs/min
