Specs
hp rating: 1250 HP
generation: T4 DIVIDED 4-BOLT
cover style: H-COVER
compressor inducer: 67.82 MM
Details
Key Features: NEXT GENERATION RACE TECHNOLOGY • HP Rating: 1250 HP • Next Gen Aero Technology including an all-new flow enhancements to the compressor housing providing 10% more flow than previous Gen 2 turbocharger compressor covers. • CEA (Competition Engineered Aerodynamics) compressor wheel machined from a 2618-aluminum closed die forging for strength & optimized air flow. • Air-cooled dual ceramic ball bearing center section (CHRA) for quick turbo response & durability. • Available in an All-New SP compressor cover w/ 4” inlet and 2-1/2”outlet and for the first time in HP compressor cover w/ 4” inlet and 3”outlet for maximum air flow. • High flow / highly efficient 75mm turbine wheel • No price increase over Gen 2. Specifications: • Compressor Wheel Inducer: 68mm • Compressor Wheel Exducer: 92.5mm 94.7 ET • Turbine Wheel Inducer: 82mm • Turbine Wheel Exducer: 75mm
