Specs
hp rating: 1000 HP
generation: T3 4-BOLT
cover style: H-COVER
compressor inducer: 64.0 MM
Details
Key Features:
NEXT GENERATION RACE TECHNOLOGY
• HP Rating: 1000 HP
• Next Gen Aero Technology including an all-new flow enhancements to the compressor housing providing 10% more flow than previous Gen 2 turbocharger compressor covers.
• CEA (Competition Engineered Aerodynamics) compressor wheel machined from a 2618-aluminum closed die forging for strength & optimized air flow.
• Air-cooled dual ceramic ball bearing center section (CHRA) for quick turbo response & durability.
• Available in an All-New SP compressor cover w/ 4” inlet and 2-1/2”outlet and for the first time in HP compressor cover w/ 4” inlet and 3”outlet for maximum air flow.
• High flow / highly efficient 66mm turbine wheel
Specifications:
Compressor Wheel Inducer: 64mm
Compressor Wheel Exducer: 86mm/ 88.1mm ET
Turbine Wheel Inducer: 74mm
Turbine Wheel Exducer: 66mm
